TP-Link TL-FC111B-20 10/100 Mbps WDM Media Converter Price in Dubai, UAE
- Complies with 802.3u 10/100Base-TX, 100Base-FX standards
- Auto-negotiation of Half-Duplex/Full-Duplex transfer mode
- 9/125 μm SMF (Single-Mode Fiber)
- Bidirectional WDM communication on a single fiber
- Ranges up to 20km (12.4 miles)
- Work with TL-FC111B-20 as a pair
Enquire on Whatsapp
Description
| Category | Specification | Details |
|---|---|---|
| NETWORK | Standards and Protocols | IEEE 802.3, IEEE 802.3i, IEEE 802.3u |
| ENVIRONMENT | Operating Temperature | 0˚C to 50˚C (32˚F to 122˚F) |
| Storage Temperature | -40˚C to 70˚C (-40˚F to 158˚F) | |
| Operating Humidity | 10% to 90% RH non-condensing | |
| Storage Humidity | 5% to 90% RH non-condensing | |
| HARDWARE FEATURES | Interface | 1× 100 Mbps SC Fiber Port, 1× 10/100 Mbps RJ45 Port (Auto MDI/MDIX) |
| Network Media | 100BASE-Tx: 2-pair UTP/STP of Cat. 5 or above (≤100 m) | |
| Power Supply | External Power Adapter: 5 V/0.6 A | |
| LED Indicators | PWR, Link/Act | |
| Wave Length | 1310 nm TX, 1550 nm RX | |
| Dimensions (W x D x H) | 94.5 × 73.0 × 27.0 mm (3.7 × 2.9 × 1.1 in) | |
| MEDIA CONVERTER & MODULE | Basic Function | Auto-negotiation of half-duplex/full-duplex, flow control (IEEE 802.3x, Backpressure) |
| Extended Fiber Distance | Up to 20 km (12.4 miles) | |
| Ports | 1× 100M single SC/UPC port, 1× 10/100M RJ45 port (Auto MDI/MDIX) | |
| WDM TX/WDM RX | TX: 1310 nm, RX: 1550 nm | |
| Network Media 10BASE-T | UTP category 3, 4, 5 cable (max 100m), EIA/TIA-568 100Ω STP (max 100m) | |
| Network Media 100BASE-T | UTP category 5, 5e cable (max 100m), EIA/TIA-568 100Ω STP (max 100m) | |
| Network Media 100BASE-FX | Single-mode fiber | |
| Safety & Emission | FCC, CE, RoHS | |
| Fiber Type | 9/125 μm single-mode fiber (≤20 km) | |
| OTHERS | Package Contents | Media Converter TL-FC111B-20, Power Adapter, Installation Guide |
