TP-Link LS109P 5-Port Gigabit Desktop Switch with 4-Port PoE+ Price in Dubai UAE
- 63 W PoE Budget: Eight 10/100 Mbps 802.3af/at-compliant PoE ports easily connect and power fixed devices like IP cameras, access points, and IP phones via a single cable. Up to 30 W PoE output is supported by each PoE port.*
- Up to 250 m PoE Transmission: With Extend Mode, PoE transmission distance reaches up to 250m, perfect for surveillance camera deployment in large areas.**
- PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices.
- Traffic Separation for Higher Security: Isolation Mode allows one-click client traffic separation to avoid snooping and tampering, and isolate broadcast storms.
- Plug and Play: Simply plug and play for instant connectivity with no configuration required.
- Silent Operation: Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses.
- Reliable Hardware Design: Durable metal casing and desktop/wall-mounting design are well-suited for different environments.
Enquire on Whatsapp
Description
| Feature | Details | Additional Information |
|---|---|---|
| Hardware Features | ||
| Interface | 9× 10/100 Mbps RJ45 Ports (8× 10/100 Mbps 802.3af/at PoE+ Ports) | AUTO Negotiation, AUTO MDI/MDIX |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) | 100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Quantity | Fanless | |
| Installation | Desktop | Wall Mounting |
| Power Supply | External Power Adapter (Output: 53.5VDC / 1.31A) | |
| PoE Ports (RJ45) | Standard: 802.3 af/at compliant | PoE Ports: Ports 1–8, up to 30 W PoE output per port, Power Supply: 63 W |
| LED Indicator | Power, Link/Act, PoE Status, PoE MAX | |
| Dimensions ( W x D x H ) | 6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm) | |
| Max Power Consumption | 3.67 W (220 V/50 Hz no PD connected) | 73.24 W (220 V/50 Hz with 63 W PD connected) |
| Max Heat Dissipation | 12.48 BTU/h (no PD connected) | 249 BTU/h (with 63 W PD connected) |
| Performance | ||
| Switching Capacity | 1.8 Gbps | |
| Packet Forwarding Rate | 1.3392 Mpps | |
| MAC Address Table | 2K | |
| Jumbo Frame | 1.5 KB | |
| Software Features | ||
| Advanced Features | Extend Mode Button (Ports 1–4/1–8, Up to 250 m PoE power supply and data transmission) | PoE Auto Recovery Button (Ports 1–8) |
| Compatible With IEEE 802.3af/at Compliant PDs | Mac Address Auto-Learning and Auto-Aging | |
| IEEE 802.3x Flow Control | Green Technology | |
| Transfer Method | Store and Forward | |
| Others | ||
| Certification | CE, FCC, RoHS | |
| Package Contents | LS109P, Power Adapter, Installation Guide, Rubber Feet | |
| Environment | Operating Temperature: 0–40 ℃ (32–104 ℉) | Storage Temperature: -40–70 ℃ (-40–158 ℉) |
| Operating Humidity: 10–90% RH non-condensing | Storage Humidity: 5–90% RH non-condensing |
