APC SRV6KRILRK Easy UPS SRV RM 6000VA 230V with External Battery Pack,with RailKit Price in Dubai UAE
Enquire on Whatsapp
Description
|
Specifications
|
||
|---|---|---|
| Model | SRV6KRILRK | |
| Product Line | APC Easy UPS On‑Line SRV | |
| UPS Type / Topology | Double‑Conversion On‑Line UPS | |
| Rated Capacity | 6000 VA / 6000 W | |
| Nominal Input Voltage | 230 V AC | |
| Input Voltage Range | ~110–300 V (half load); ~176–300 V (full load) | |
| Input Frequency Range | 40–70 Hz (auto‑sensing) | |
| Input Connection | Hard‑wired (Phase + Neutral + Earth) | |
| Nominal Output Voltage | 230 V AC | |
| Selectable Output Voltages | 220 / 230 / 240 V | |
| Output Frequency | 50/60 Hz ± 3 Hz (sync to mains) | |
| Waveform Type | Pure sine wave | |
| Output Voltage Distortion (THD) | Typically ≤ 3% | |
| Crest Factor | 3:1 | |
| Bypass | Automatic & Manual Internal Bypass | |
| Efficiency (Full Load) | ~94% | |
| Battery Type | Maintenance‑free sealed lead‑acid (external battery pack included) | |
| Battery Configuration / Voltage | High-voltage external battery string | |
| Typical Recharge Time | ~3–8 hours to 90% (depending on battery pack) | |
| Runtime (Approx.) | Extended runtime with external battery pack; varies by load and configuration | |
| Rack Form Factor | 5U rack‑mount (rail kit included) | |
| Display / Interface | Multifunction LCD status panel | |
| Communication Ports | RS‑232, USB, Intelligent (SmartSlot) expansion slot | |
| Emergency Power Off (EPO) | Supported | |
| Operating Temperature Range | 0 °C – 40 °C | |
| Operating Humidity | 0 – 95% (non‑condensing) | |
| Weight (Approx.) | ~65 kg (base unit; varies with external battery) | |
| Applications | Servers, network equipment, data centers, telecom infrastructure | |
